Specifications

Main Board Name: X7C

CPU: Intel® Bay Trail-Mobile/Desktop SoC Processor:

• Celeron® J1900 (4 cores, up to 2.42 GHz, TDP 10 Watt)

System Memory: SO-DIMM DDR3L 1067/1333MHz x 1, Max. 8GB

Graphic: Intel® HD Graphics

BIOS: Phoenix uEFI BIOS

O.S. Support:

• Windows Embedded POSReady 7
• Windows 7 Professional for Embedded Systems
• Windows Embedded 8.1 Industry
• Windows 10
• Linux kernel 3.0+ & associated distributions
• Android 4.4.4 Compliant OS

Cooling Solution: Fan-less

Interface: SA TA2 (3.0Gb/S) x 2

HDD or SSD:

• 2.5" SATA HDD / SSD x 1
• mSATA slot x 1

I/O Ports

Serial:

• Serial Port x 6, DB-9 Pin9 with RI/5V/12V selectable by BIOS.
• COM 1 / 2: RS-232, RJ-50 with convert to DB-9 cable
• COM 3: RS-232/422/485, DB-9
• COM 4 / 5 / 6: RS-232, DB-9

USB:

• USB 3.0 x 1
• USB 2.0 x 6

Cash Drawer: RJ-12 x 1, support 12V / 24V DC cash drawer

Audio: Line out x 1

VGA: DB-15 with 0/12VDC power (Setting by BIOS) x 1

Expansion Slot: Half size Mini PCIe x 1

DP / HDMI: Mini DisplayPort x 1 (supporting active converter cable to VGA, DVI, HDMI)

DC-in: 19VDC input, 2-pins radio jack x 1

LAN: Gigabit Ethernet by RJ-45 x 1, support Wake on LAN

DC-out: 12VDC/1A output, 2-pins radio jack x 1

Physical Dimensions

Dimension ( WxDxH ): 20.2 x 14 x 5.5 cm (8 x 5.5 x 2.2 inch)

Net Weight / Gross Weight: 1.2 kg, 2.6 Ib / 2.7 kg, 6 lb

Others

Mounting mechanism: Support VESA Mount (75x75 / 100x100mm available)

Connectivity: Wireless LAN module, half size mini PCIe type (Optional)

Power Supply: External adapter, 65W, 19V DC input

Color: Black

Material: SECC / Silicon Rubber

Certifications: FCC / CE / RoHS / VCCI / WEEE

Ingress Protection: IP32

Environmental Conditions

Storage Temperature: -20°C ~ 60°C

Humidity: 20% to 85% RH (non-condensing)

Operating Temperature: 0°C ~ 50°C
