Specifications

CPU: Intel Skylake Core i3-6100U, Dual Core, 2.30 GHz, 3M cache

Memory: DDR4 SO-DIMM slot x 2, max 16 GB, default 8 GB

Storage device(s): In Australia Standard with 128 GB SSD, can also be purchased with a 500 GB SATA HDD (Special Order) or larger SSD Drives

Display: 21.5" TFT LED Backlit LCD Display

Resolution: 1920 x 1080

Touch Panel: True-flat PCAP touch with multi-touch support

I/O Ports:

• 6 x RS-232 Ports (3 x DB9, 1 x 10 pin RJ50) with 5V/12V Support
• 6 x USB Ports (1 x USB3.0/2.0 6 x USB2.0)
• 1 x 10/100/1000Mb Ethernet Port
• 1 x M.2 slot

Audio: Internal 3W speaker x 2

OS Support: Windows 7/POSReady 7/Windows Embedded 8.1 Industry/Windows 10 IoT/Linux per request

Options:

• Standard Pedestal or Countertop
• Wifi/BT Module
• 2D Barcode Scanner
• Proximity Sensor
• Wide Angle Camera
• Custom Brackets for Payment terminals
• MSR
• Fingerprint reader
• NFC Reader
• With Expansion Pedestal option add:
• Ticket Printer
• Card dispenser

Environmental Sealing: N/A

Operating Environment:

0 ~ +50 °C, 20 ~ 90% RH with SSD

0 ~ +40 °C, 20 ~ 90% RH with HDD

Storage Environment: -20 ~ +70 °C, 10 ~ 90% RH

Power Supply

External Dimensions (WxDxH): 400mm x 330mm x 1621mm (With Pedestal)

Weight: 60 Kg
